LG MaxRO R

The LG MaxRO R is LG Chem’s flagship membrane, combining Thin-Film Nanocomposite (TFN) technology with a groundbreaking 36-mil feed spacer (0.9144 mm) featuring ultra-low dP (ULD). This innovative design enhances filtration efficiency, achieving a salt rejection rate of up to 99.8%, a permeate flow rate of 11,500 GPD (43.5 m³/d), and optimized operational costs.

Brand: LG Chem – NanoH2O

Product Type: BWRO membranes

Product features

Combines Thin-Film Nanocomposite (TFN) technology and 36-mil Feed spacer technology to maximize salt rejection (up to 99.8%) and reduce operational costs (lower chemical cleaning requirements, extended membrane lifespan, and energy savings).
Suitable for a wide range of applications and water sources.
Meets NSF/ANSI/CAN 61 for drinking water systems.

Specification

Permeate flow rate

11,500 GPD (43.5 m³/d)
Stabilized salt rejection

99.8%
Minimum salt rejection

99.5%
Maximum applied pressure

600 psi (41.3 bar)
Active membrane area

400 ft² (37 m²)
Feed spacer thickness

36 mil, ultra-low dP (ULD)

The LG MaxRO R is designed to optimize water treatment performance with its modern 36-mil Feed spacer technology. It delivers exceptional salt rejection of up to 99.8%, energy savings, and extended system lifespan. Below is detailed information to help you evaluate its performance and applications.

1. Technical specifications of the LG MaxRO R membrane

Understanding the technical specifications is essential for accurately assessing the membrane’s performance. Below are the key specifications of the LG MaxRO R:

SPECIFICATION	VALUE
Permeate flow rate	11,500 GPD (43.5 m³/d)
Stabilized salt rejection	99.8%
Minimum salt rejection	99.5%
Active membrane area	400 ft² (37 m²)
Feed spacer thickness	36 mil, ultra-low dP (ULD)

2. Operating specifications of the LG MaxRO R membrane

To ensure optimal performance and longevity, please adhere to the following operating specifications:

SPECIFICATION	VALUE
Maximum applied pressure	600 psi (41.3 bar)
Maximum chlorine concentration	< 0.1 ppm
Maximum operating temperature	45°C (113°F)
pH range, continuous operation	2 – 11
pH range, cleaning	1 – 13
Maximum feed water SDI₁₅	5.0
Maximum feed water turbidity	1.0 NTU
Maximum feed flow	75 gpm (17 m³/h)
Maximum pressure drop (ΔP) for each element	15 psi (1.0 bar)

3. Key features of the LG MaxRO R membrane

The LG MaxRO R integrates cutting-edge technologies, including Thin-Film Nanocomposite (TFN) and 36-mil ULD (ultra-low dP) fFed spacers, to enhance filtration efficiency and reduce operational costs:

Highest salt rejection: Achieves up to 99.8% salt rejection, ensuring consistent, high-quality permeate water.
Cost optimization: Reduces chemical use and cleaning frequency, membrane replacements, and stable performance recovery after cleanings.
Versatility: Suitable for various water treatment systems, including industrial process water, municipal drinking water, and wastewater reuse.

Key features of the LG MaxRO R membrane — *Highlights of the LG MaxRO R membrane*

4. Advantages of the LG MaxRO R membrane

Unlike conventional RO membranes using 28 – 34 mil feed spacers, the LG MaxRO R features a breakthrough 36-mil ULD feed spacer, significantly reducing differential pressure by up to 60%.

Its unique three-layer design optimizes flow, minimizes fouling, reduces energy consumption, and extends membrane lifespan, setting it apart from competitors:

Improved water quality: Enhances permeate water quality without increasing operating pressure.
Energy efficiency: Reduces energy consumption, lowering long-term operational costs.
Anti-fouling properties: Minimizes fouling, extending cleaning cycles and membrane lifespan.
Certified safety: Complies with NSF/ANSI/CAN 61 for drinking water system components.
Ideal for large systems: Perfect for large-capacity RO systems, especially in wastewater reuse and brackish water treatment.

5. Certifications of the LG MaxRO R membrane

The LG MaxRO R is certified to NSF/ANSI/CAN 61 for drinking water system components.

For detailed certification information, visit: LG MaxRO R Certification

6. Applications of the LG MaxRO R membrane

Thanks to its anti-fouling properties, energy efficiency, and optimized flow, the LG MaxRO R is suitable for a variety of applications, including:

Industrial process water: Providing pure water for manufacturing processes.
Municipal water supply: Delivering high-quality water for domestic use.
Wastewater reuse systems: Reducing water waste and protecting the environment.
ZLD (Zero Liquid Discharge) and MLD (Minimal Liquid Discharge) systems: Ensures efficient water management in demanding applications.
